• Oversize capabilities to 12 ft high

  • More Natural Light

  • Energy-efficient, sustainable and environmentally focused

  • Meets and exceeds most rigorous energy codes and guidelines

  • Endless design options such as custom finishes, glass choices, shapes, and sizes

Performance

Features

Technical Parameters

  • Water Tightness: 9 psf
  • Designed Pressure: CW 60 psf
  • Thermal Insulation: From 0.15 Btu/hft2F
  • Acoustic Insulation: STC up to 44 dB
  • Maximum Panel Weight: 550 lbs (250 kg)
  • Maximum Panel Height: 10 ft (3 m)
  • Maximum Panel Width: 4.5 ft (1,4 m)

Accessories

Standard

RAL 7016
RAL 9005
RAL 9007
RAL 9016

Special 1

Smooth Carriage
CLassic 31
Classic 35
Metallic Grey

Special 2

Night Promise
Pistache
Royal Green
Perfect Aubergine

Woodgrain

Bright Oak
Sour Cherry
Walnut
Winchester

Anodized

C-0-S Anodized Natural Silver
C-31-S Anodized Inox
C-32-S Anodized Champagne
C-35-S Anodized Black

Thickness

Min: 0.24" (6 mm)

Max: 1.81" (46 mm)

Glazing

Double

Triple

Glass Types

Laminated

Tempered

Extras

High Altitude

Acoustic Insulated

Bird / Turtle Friendly

Priva Lite Switch Glass

Spandrel / Frit / Lacobel

Door Hinge - Non Visible

Door Hinge - Visible

Standard

Cubic

Contemporary

Inox

SDL in pane

SDL interior/exterior

Downloads

AVAILABLE UPON REQUEST
